QP3TH TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #9 (02/20/18) — PAGE 35
PUMP ASSEMBLY
NO. PART NO. PART NAME QTY. REMARKS
38 0181090820 BOLT SET W/SPRING WASHER M8 X 20 2
(SUCTION PLATE)
39 0181090825 BOLT SET WITH SPRING WASHER M8 X 25 4
(SUCTION COVER)
40 0151191257 STUD BOLT, (DRAIN COVER HANDLE) 4
M12 X 57 X15 X 22
41# 0520040431 KEY, IMPELLER 1
42 43342012400011 IMPELLER WASHER, DIA. 42 X 12 MM T4.5 1
43 0204490060 U-NUT, WEAR PLATE M6 3
44 0458220080 SEAL, WASHER, CASING COVER M8 4
45 0205490100 NUT, ENGINE M10 4
46 0205490100 NUT, CUSHION RUBBER M10 8
47 0205490100 NUT, PUMP M10 2
48 0401650100 WASHER, ENGINE M10 4
49 0451290080 SPRING WASHER, (VOLUTE CASING) M8 4
50 0451290080 SPRING WASHER (DRAIN COVER SET HANDLE) M8 4
51 0451290100 SPRING WASHER, (CUSHION RUBBER) M10 8
52 0451290100 SPRING WASHER, (ENGINE) M10 4
53 0451290100 SPRING WASHER, (PUMP) M10 2
54 0451290100 SPRING WASHER, (CASING COVER SET PLATE) M10 4
55 0480570850 O-RING, (VOLUTE CASING) 1
56 1992108050 CAP 1
57 0742214080 STRAINER 1
58 GX240K1QA2 ENGINE, HONDA 7.1 HP ......................................1............S/N 3TH-4853 AND BELOW
58 GX240U1QA2 ENGINE, HONDA 7.1 HP ......................................1............S/N 3TH-4854 TO 3TH-20727
58 GX240UT2QA2 ENGINE, HONDA 7.1 HP ......................................1............S/N 3TH-20728 AND ABOVE
61 KIT3TE KIT MECHANICAL SEAL, SLEEVE, & O-RINGS ........1............INCLUDES ITEMS W/@
