Page 7
Heat
Case - 4
Cool
Case - 5
/
/
IF
Individual
IF On-OFF Select
IF Relative
CONTROL FUNCTION
RLY-OFF
RLY-ON
delay delay delay
Time Time Time
RLY-ON
RLY-ON
RLY-ON
RLY-OFF
RLY-OFF
RLY-OFF
Temp.
Temp.
S.V
HYST
HYST
S.V
Time
Time
OFF
OFF OFF OFF
OFF
ON - OFF control (Heating)
ON - OFF control (Cooling)
ON
ON ON ON
ON
PID AUTO-TUNING
Press key for 6 sec to start/stop
PID auto-tuning
°C
PV
O/P
Tuning
LED Indication
SV
Auto Tuning:-
The Auto-tuning function automatically computes
and sets the Proportional band (Pb) , Integral time (It),
Derivative time (dt), and cycle time as per process
characteristics.
Tuning LED will turn “ON” during Auto-Tuning
If the power goes off before auto-tuning is completed,
auto-tuning will be restarted at next power ON.
R
Specifications are subject to change, since development is a continuous process,
So for more updated operating information and Support,
Please contact our Helpline: 9978991482/9978991476/9978991474 or
Email at Ver:191201service@multispanindia.com
