MULTISPAN VPR-22 - Terminal Connections and Specifications; Terminal Connection Diagram; Power Supply and Input Voltage; Output Specifications

Terminal Connection:
L1-L2
L2-L3
L3-L1
T
ON ON
P
15
18
16
T
T
Phase
Loss
ON ON
< 280V AC (L-L)
Phase Loss
40V AC (L-L)
Phase Asymmetry
6 V
Hysteresis
= Power ON Delay (5 sec)
Over Voltage
Under Voltage
Hysteresis
Hysteresis
TP
T
= Trip Delay (5 sec)
L1
L3
16
15
18
L2
Output :
1 Relay 1C/O ,
5A, 230V AC (Res.)
Input Voltage:
280 to 520V AC (L-L)
3Ø - 3W
Function :
Phase Loss < 280V AC (L - L)
Phase Asymmetry > 40V Fix
Hysteresis : 6V Fix
Rated Voltage: 415V AC (L-L)
-
Self Powered
NO
C
NC
18 15 16
Power Supply :
Delay Time :
Trip Delay: 5 Sec.
Power ON Delay: 5 Sec.
PS,PL: <200ms
Asymmetry: 5 Sec.
-
LED Indication:
RED: PL
Blinking Red: PA
Yellow: PS
OFF: Healthy
Control Function:
Terminal Connection:
