MULTISPAN VR-3KN - Page 2

Terminal Connection:
L1-L2
L2-L3
L3-L1
T
ON ON
P
08
07
09
T
T
Phase
Loss
ON ON
< 100V AC (L-N)
Phase Loss
± 40V AC (L-L)
Phase Asymmetry
6 V
Hysteresis
= Power ON Delay (5 sec)
Over Voltage
Under Voltage
Hysteresis
Hysteresis
TP
T
= Trip Delay (0 to 15 sec selectable)
(For OV & UV)
Function :
Phase Loss < 280V AC (L - L)
Phase Asymmetry ± 40V Fix (L - L)
Hysteresis : 6V Fix
Rated Voltage: 415V AC (L-L)
Delay Time :
Power ON Delay: 5 Sec.
Trip Delay : 0 to 15 Sec Selectable
(For OV & UV)
Trip Delay : <200ms (For PS & PL)
Trip Delay : 5 Sec (Asymmetry)
Recovery Time : 2 Sec
-
LED Indication:
R: Relay
UV : Under Voltage
OV : Over Voltage
PL : Phase Loss
AS : Asymentery
PS : Phase Sequence
Control Function:
Terminal Connection:
160 To 300V AC (L-N)
230V AC (L-N)
100V AC (L-N)
N
3ø-4W
VR-3KN
