Multistack MS085XC - System Wire and Fuse Sizing

28
VOLTAGE 208 230 460 575
MS010X* 13.1/136 11.8/136 5.9/66.1 4.7/55.3
MS015X 24.8/240 22.4/240 11.9/130 9.1/93.7
MS020X 28.1/240 25.4/240 13.9/140 10.7/107.6
MS030X 49.8/340 45.0/340 22.5/173 18.0/132
MS040X 54.0/538 49.0/538 23.5/229 19.5/180
MS050X 67.0/605 60.0/605 30.0/272 24.0/215
MS070X 89.0/599 80.0/599 40.0/310 32.0/239
MS085X 112.8/943 102.0/943 51.0/408 37.6/375
MCA
3 CONDUCTORS
1 CONDUIT
6 CONDUCTORS
2 CONDUIT
50 8 —
65 6 —
85 4 —
100 3 —
115 2 —
130 1 —
150 1/0 —
175 2/0 —
200 3/0 —
230 4/0 —
255 250 MCM —
285 300 MCM 1/0
300 — 1/0
350 — 2/0
400 — 3/0
460 — 4/0
500 — 250 MCM
System Wire & Fuse Sizing Specications
Compressor Rated Load Amps (RLA) and Locked Rotor Amps (LRA) Data
Standard and Total Access™ Modules
RLA/LRA
1. Wiring Sizing: Minimum Circuit Ampacity (MCA) MCA = (1.25 x RLA1*) + RLA2 + RLA3
2. Fuse Sizing: Maximum Fuse (MF), Type RK5 Fuse
MF= (2.25 x RLA1*) + RLA2 + RLA3
Where MF does not equal a standard size fuse, the next larger size fuse should be used.
NOTES:
A. *RLA1 = RLA of the largest compressor in the system. RLA2 & RLA3 = RLA of the other compres-
sors in the system.
B. Total system Minimum Circuit Ampacity (MCA) shall not exceed 500A.
C. Wire sizing is based on the National Electrical Code (NEC) rating for 75°C copper wire, with 3
wires per conduit.
D. Wiring distance from branch circuit shall not exceed 100 feet.
* MS010X units are also available for single-phase power (230/1/60 )
applications and have an RLA of 19.5 amps and LRA of 178 amps.
DANGER: To avoid the risk of electrical shock, personal injury or death, disconnect all
electrical power to the unit before performing any maintenance or service. The unit may have
more than one electrical power supply. Assume all electrical wires are live, energized wires. Use
lockout/tagouts.
(Applicable codes may require dierent wire
sizing)
