Multitech MTC-MAT1-B01 - MTC-MVW1 Power Draw

PRODUCT OVERVIEW
14 MultiConnect
®
Cell MTC Cat M1 User Guide
USB model (B03)
Radio
protocol
Sleep mode
(mA)
1
Power save
mode (mA)
Live idle
(mA)
2
No data
(mA)
3
Max power
(mA)
4
TX pulse
(mA)
5
Inrush charge
(mC)
6
5 Volts
LTE N/A 6 36 35 125 212 0.596
Note:
1
Sleep mode: Sleep mode current, connected to wireless (milliamps).
2
Live idle: Live Connection Idle Current (milliamps).
3
No data: Cellular call box connection, no data (milliamps).
4
Max Power: Average measured current (milliamps) at maximum power. The continuous current during
maximum data rate with the radio transmitter at maximum power.
5
TX pulse: Average TX pulse amplitude current (milliamps). The average peak current during a transmission
burst period.
6
Inrush charge: Total inrush charge (millicoulombs). The total inrush charge or input current at power up, or
reset.
7
Inrush duration: Total inrush charge duration during power-up (milliseconds).
MTC-MVW1 Power Draw
Serial model (B01)
Radio
protocol
Sleep
mode
(mA)
1
Power save
mode (mA)
Live idle
(mA)
2
No data
(mA)
3
Max power
(mA)
4
TX pulse
(mA)
5
Inrush
charge
(mC)
6
Inrush
duration
(ms)
7
9 Volts
LTE 700
MHz
9 20 26 25 70 132 0.762 9.0
12 Volts
LTE 700
MHz
7 19 24 24 58 124 0.768 7.4
24 Volts
LTE 700
MHz
4 10 14 14 41 108 1.16 23.0
