MultiConnect Adapters
Multi-Tech Systems, Inc. Quick Start Guide 5
Serial-to-Serial Setup Example
Serial-to-Serial Power Supply Connection:
MultiConnects are powered in one of two ways:
Powered by External Power Supply
MTS2SA-T
RS-232 Power (Pin 6)
MTS2SA-T-R
RS-232 Connector
RS-232 & External Power Connectors
RS-232 Connector
RS-232 Power Pin Connector
