1 Introduction to MultiSmart
MultiSmart is a pump station manager - a new category of product - which combines the best of pump
controller functionality, PLC flexibility, an RTU, and some control panel components.
The main functional blocks of MultiSmart include:
• Pump controller –extensive functionality to cover single pump through to 9 pump applications,
including multiple groups of pumps
• Flow module – handles calculated flow or flow meters with common tags
• Supply protection – directly measures 3-phase supply and provides monitoring, datalogging and
voltage protection
• Energy, power and motor protection module – measures 3-phase currents for each pump from
CTs, calculates power, power factor, apparent power, energy, apparent energy, and provides
motor protection functions; measures insulation resistance via 1000v megger test
• RTU – Modbus master/slave, DNP3 master/slave, allowing multiple masters and slaves (DNP
security will be implemented in v2.0, available in Q3 2008)
• Custom logic – via “mini-logic engine”
• PLC functionality (all 5 languages) to IEC61131-3 standard (available from v2.0 of the product)
Pump Controller RTU
Power & Energy
Monitoring/
Motor Protection
Supply Protection/
Monitoring
Data Logger
Flow
Fault Module
Security
Logic Engine
Pumps
& Groups
Station
Optimization
Profiles
Fill/Empty & Pump
Setpoints, Alarm
Setpoints, Delays
Level
Sensing
Medium
RS232
TCP/IP
UDP/IP
Cellular
PLC - IEC61131-3
(IsaGRAF)
Additonal Master & Slaves
DNP3 Master/Slave
Additonal Master & Slaves
Modbus Master/Slave
Figure 1 – Functional Blocks available in MultiSmart
