5.5 Intermediate 2-pump application – 54 tags
Description Tag ID
DNP ID
(default)
Modbus ID
(default)
Comments
Pump 1
Pump 1 Running
(called)
PumpControl.Pump._1.Running
Binary
Input 70
Discrete
Input 62
Pump 1 Mode
(Auto/Off/Manual or
Hand)
PumpControl.Pump._1.PumpMode
Analog
Output 18
Holding
Register 18
5 states: 0 – Auto, 1 – Manual, 2 – Semi-auto, 3 – Off, 4 - Decommissioned
Pump 1 Unavailable PumpControl._1.FaultStatus.UnavailableActive
Binary
Input 73
Discrete
Input 65
The pump can be unavailable when supply faults are present as well as when
pump faults exist.
A pump fault does not have to make the pump unavailable, e.g. the default
configuration for a seal fault.
Any fault can be defined to be a display only fault, an auto reset fault (pump
becomes available when fault condition clears), or a manual reset fault (pump
only becomes available when manual or SCADA reset takes place)
Pump 1 Thermal
overload fault active
Faults.Pump._1.ThermalOverload.Status.Active
Binary
Input 76
Discrete
Input 68
Pump 1 Thermal C/B
off trip fault active
Faults.Pump._1.CBOffTrip.Status.Active
Binary
Input 104
Discrete
Input 96
Pump 1 Contactor
Auxiliary fault active
(pump failed to start)
Faults.Pump._1.ContactorAux.Status.Active
Binary
Input 98
Discrete
Input 90
Pump 1 Motor
Overtemp fault active
OR if Flygt FLS used
Faults.Pump._1.MotorOvertemp.Status.Active
Faults.Pump._1.FlsThermal.Status.Active
Binary
Input 102
Binary
Input 80
Discrete
Input 94
Discrete
Input 72
Pump 1 Seal fault
active
OR if Flygt FLS
Faults.Pump._1.Seal.Status.Active
Faults.Pump._1.FlsSeal.Status.Active
Binary
Input 74
Binary
Input 78
Discrete
Input 66
Discrete
Input 70
Pump 1 Fault Reset Faults.Pump._1.GroupManualReset
Binary
Output 20
Coil 20 This will reset all unacknowledged faults for this pump
Pump 2
Pump 2 Running
(called)
PumpControl.Pump._2.Running
Binary
Input 130
Discrete
Input 122
Pump 2 Mode
(Auto/Off/Manual or
Hand)
PumpControl.Pump._2.PumpMode
Analog
Output 24
Holding
Register 24
5 states: 0 – Auto, 1 – Manual, 2 – Semi-auto, 3 – Off, 4 – Decommissioned (only
Auto, Semi-Auto, and Off can be written to, see Note 6 )
Pump 2 Unavailable
PumpControl.Pump._2.FaultStatus.UnavailableActiv
e
Binary
Input 133
Discrete
Input 125
