Pump 2 Thermal
overload fault active
Faults.Pump._2.ThermalOverload.Status.Active
Binary
Input 136
Discrete
Input 128
Pump 2 Thermal C/B
off trip fault active
Faults.Pump._2.CBOffTrip.Status.Active
Binary
Input 164
Discrete
Input 156
Pump 2 Contactor
Auxiliary fault active
Faults.Pump._2.ContactorAux.Status.Active
Binary
Input 158
Discrete
Input 150
Pump 2 Motor
Overtemp fault active
OR if Flygt FLS
Faults.Pump._2.MotorOvertemp.Status.Active
Faults.Pump._2.FlsThermal.Status.Active
Binary
Input 162
Binary
Input 140
Discrete
Input 154
Discrete
Input 132
Pump 2 Seal fault
active
OR if Flygt FLS used
Faults.Pump._2.Seal.Status.Active
Faults.Pump._2.FlsSeal.Status.Active
Binary
Input 134
Binary
Input 138
Discrete
Input 126
Discrete
Input 130
Pump 1 Fault Reset Faults.Pump._2.GroupManualReset
Binary
Output 22
Coil 20 This will reset all unacknowledged faults for this pump
Level
Level (scaled) PumpControl.Well._1.ScaledLevel
Analog
Input 12
See Note 3
High high level alarm Faults.Well._1.HighHighLevel.Status.Active
Binary
Input 30
Discrete
Input 28
High level alarm Faults.Well._1.HighLevel.Status.Active
Binary
Input 32
Discrete
Input 30
Low level alarm Faults.Well._1.LowLevel.Status.Active
Binary
Input 34
Discrete
Input 32
Low low level alarm Faults.Well._1.LowLowLevel.Status.Active
Binary
Input 36
Discrete
Input 34
Level alarm reset Faults.Well._1.GroupManualReset
Binary
Output 8
Coil 8 This resets all well faults, see note 5
Supply
Undervoltage fault Faults.Station.UnderVoltage.Status.Active
Binary
Input 0
Discrete
Input 0
Overvoltage fault Faults.Station.OverVoltage.Status.Active
Binary
Input 2
Discrete
Input 2
Phase fail fault Faults.Station.VoltsPhaseImbalance.Status.Active
Binary
Input 4
Discrete
Input 4
Phase rotation fault Faults.Station.VoltsPhaseRotation.Status.Active
Binary
Input 6
Discrete
Input 6
Supply fault reset Faults.Station.GroupManualReset
Binary
Output 1
Coil 1 This resets all station faults, see note 6
Supply, phase AB IO.Unit._1.TopBoard.Vin._1.VoltsAb
Analog
Input 47
Input
Register
113
