Supply, phase BC IO.Unit._1.TopBoard.Vin._1.VoltsBc
Analog
Input 48
Input
Register
114
Supply, phase CA IO.Unit._1.TopBoard.Vin._1.VoltsCa
Analog
Input 49
Input
Register
115
DC supply IO.Unit._1.DcVolts.Input.Value
Analog
Input 40
Input
Register
106
Flow
Inflow Flow.InflowRate
Analog
Input 4
Input
Register 21
Value in gals or litres /sec depending on units configured in the product
Pump 1 Flow rate Flow.Pump._1.FlowRate
Analog
Input 21
Input
Register 63
Pump 2 Flow rate Flow.Pump._2.FlowRate
Analog
Input 31
Input
Register 93
Station volume Flow.VolumePumped Counter 4
Input
Register 22
Overflow fault active Faults.Station.Overflow.Status.Active
Binary
Input 18
Discrete
Input 18
Setpoints
Lead pump activation
setpoint
PumpControl.Behaviour._1.ActSetPoint
Analog
Output 19
Holding
Register 19
In the tag database, the lead pump is known as “behaviour 1”, lag pump
“behaviour 2” and so on. If alternation is off, i.e., fixed sequence, then Behaviour
1 is the first pump to run.
Lead pump de-
activation setpoint
PumpControl.Behaviour._1.DeactSetPoint
Analog
Output 20
Holding
Register 20
Lag pump activation
setpoint
PumpControl.Behaviour._2.ActSetPoint
Analog
Output 25
Holding
Register 25
Lag pump de-
activation setpoint
PumpControl.Behaviour._2.DeactSetPoint
Analog
Output 26
Holding
Register 26
Power, energy & efficiency
P1 Pump efficiency,
yesterday
MotorProt.Pump._1.EfficiencyYesterday
Frozen
Counters
133
See Note 4 Gals or litres / kWHr.
P1 Power, KW IO.Unit._1.BottomBoard.Power._1.Power
Analog
Input 84
Input
Register
156
Value in KW
P1 power factor IO.Unit._1.BottomBoard.Power._1.PowerFactor
Analog
Input 85
Input
Register
157
P1 Energy, KWHr IO.Unit._1.BottomBoard.Power._1.EnergykWh
Analog
Input 86
Input
Register
158
To capture energy used yesterday (for daily analysis) use
IO.Unit._1.BottomBoard.Power._1.EnergyYesterdaykWh, which is DNP Frozen
Counters 129 (no default Modbus equivalent)
