NOTE :ForadditionalinformationontheLM500(specificationsandinstallationinst ructions),
searchLM500ontheFWMurphyWebsite( www.fwmurphy.com ).AttheLM500Webpage,
selectthe Literature tabandchoose InstallationInstructions .
5
Lineupboltholepattern,pushfromcenteroflens,andinstall
finger‐tightsix(6)shoulderbolts.(SeeStep6fortorque
instructions.)
6
Useatorquewrench/torquegunsetat12in‐lbstoattachthescrews.
Tightenscrewsusingacrosspattern.(12in‐lbsisapproximatelyequivalentto1/8turnafterthe
shoulderboltbottomsout.
