Murphy PowerCore MPC-20 User Manual

Section 40 00-02-0897
2015-10-22 - 9 -
Specifications
Electrical
Display: 3.8” Monochrome, Transflective, White Backlight LCD
Operating Voltage: 8-32 VDC, protected against reverse battery
polarity and load-dump
Power Consumption: 18W max without 2 2A High-sides active,
146W max with 2 2A High-sides active
Communications
2-CAN: J1939
USB: 2.0B (Only supported for programming)
Ethernet: (Not supported in initial release)
RS485: Modbus RTU
Connection: Delphi SICMA 90 way connector, 1.5mm
Keyboard: 11 tactile feedback buttons
Inputs
6-Digital Inputs: high/low
8-Analog Inputs: configurable (4-20mA, 0-5V,
resistive)
1-Frequency Input: supporting Magnetic Pickup or
Engine Alternator
(2 Hz – 10 KHz, 3.6 VAC – 120 VAC)
Outputs
6-Relays: 10A, SPDT, Form C (30 VDC @ 10A or 125
VAC @ 10A max.), 40A maximum aggregate @ 85C
2-Low-side Outputs: 1A
2-High-side Outputs: 2A
2-5V Outputs: 200mA (to drive external relays)
1-Analog Output: 0-5V
Real-time clock: with battery backup
