VS-7037N page 5 of 8
TYPICAL MOUNTING LOCATIONS
Engine Compressor
Turbine Centrifugal
Compressor
Engine
and
Vertical
Shaft
Pump
“Y” Type
Reciprocating
Compressor
Generator
Sets
Cooling Tower Fan or
Heat Exchanger
Pumping Unit
2-Throw Balance-Opposed Compressor
NOTE: If installing on
cylinders, 2 vibration/shock
switches are recommended-
1 for each cylinder.
Reset
Reset
Reset
Reset
Reset
Reset
Reset
Reset
Reset
These are typical mounting locations for best operation. Other mountings are possible.
See
Installation section on page 3.
NOTE:
