Murray 461000x8A - Sector Gear

REPAIR PARTSMODEL 461000x8A
45
F–030718L
SECTOR GEAR
1
2
3
4
5
6
7
8
9
10
11
7
6
12
13
Key
No. Description
Part
No.
1 Bolt, Shoulder 009x62
2 Nut, Lock 15x111
3 Nut, Flange 015x79
4 Guide, Screw 094384
5 Link, Left Drag 690146E700
6 Washer 17x168
7 Nut, Flange 015x84
8 Link, Right Drag 690145E700
9 Bolt 001x84
10 Bearing, Sector Gear 690180
11 Fitting, Lub 092530
12 Gear, Sector 690147
13 Plate, Steering 1001121E701
