PARTS LIST
No. Description QTY No. Description QTY
1 Main frame 1 36 Nylon nut M8 2
2L/R Left and right upright post 1/1 37 Foot pedal cover 2
3 Front stabilizer 1 38 Tension controller 1
4a/b Left handlebar cover 1pair 39 Flat washer φ5 7
5a/b Right handlebar cover 1pair 40 Cross pan head screw M5×18 1
6 Handlebar 2 41 Top cover 1
7 Fixed handlebar 1 42 Front and rear roller shaft 1
8 Computer 1 43
Plastic flat washer φ12
4
9 Edge strip 2 44 Inertia wheel (front rolling drum) 1
10 Running belt 1 45
Flat washer φ8
1
11 Running board 1 46 Magnetic board 1
12 Trimmer line hole plug 1 47 Square magnetic block 4
13 Cross pan head screw 2 48 Square tube plug 2
14 Foam 2 49 Cross pan head screw M6×16 2
15 Cross pan head screw M5×12 8 50
Flat washerφ6
12
16
Cross pan head self tapered screw
ST4×12
6 51 Cross pan head self tapered screw ST3×10 2
17 Round tube plug 2 52 Sensor wire 1
18 Handlebar cover 2 53 Z shape block 1
19 Bottle (IF HAVE) 1 54 Intrinsic sticky plastic fixing block 1
20
Hexagon socket pan head screw
M8×20
5 55 Frame tube 2
21 Compression spring 1 56 Cross recessed tapered screw ST4.2×13 16
22 Pulse sensor 2 57 ABS pad 6
23 Pulse wire 2 58 Cross recessed head screw M6×38 8
24 Sensor connection wire 1 59 Nylon nut M6 8
25 Sensor connection wire 1 60 Rubber pad 2
26 Pin 1 61 Rear rolling drum 1
27 Flat washer 2 62 Rear rolling drum axle 1
28
Hexagonal socket pan head screw
M10×80
2 63 Hexagon socket head cap screw M6×55 2
29 Blossom knob 1 64 EVA pad 2
30
Hexagonal socket pan head screw
M10×20
4 65L/R
Left and right trimmer 1/1
31 Arc washer φ10 4 66 Pan-head self-tapered screw ST4.2×13 4
32 Bottom seat rubber pad 4 67 Rear rolling drum 1
33
Cross pan head self-tapered screw
ST4.2×19
8 68 End cap 2
34
Hexagon socket head cap screw
M8×45
2 69 Rubber pad 4
35 Bottom seat rolling wheel 2
