Muse M15 - Page 25

Oset Adjustment: If you are cutting rectangular paths and nd that paths which should have 90° angles are
instead rounded, the Blade Oset is too low. If the angles are sharp but distorted, the oset value is too high:
In either case, you will need to adjust the Blade Oset value in LXi Production Manager (see Section 2.5) or
in Create Space (see FIG. 2.6.1). These are the base settings for each type of Muse blade:
30° yellow capped: 0.75 mm (0.03 in)
45° red capped: 0.3 mm (0.01 in)
60° blue capped: 0.4 mm (0.02 in)
Overcut
2.2.3
Correct Oset Too Low Too High
If your test cut has gaps in the paths or if the corners were not cut precisely, you may need to adjust the Overcut
setting. This can be done on the Default Job Properties tab in the LXi Production Manager (see Section 2.5) or in
the Cut Settings window in Create Space (FIG. 2.6.1).
Presets allow you to save your settings for a material. The Muse can save up to 8 presets. The pre-loaded presets
are for EnduraGloss, Holographic and Oracal 651 vinyl, EnduraLITE reective sheeting, and EasyWeed, Logical
Color Warm Peel Universal, HotMark 70, and Logical Color GlitterSoft heat transfer lm (HTV). Remember, these
are just pre-loaded for your convenience and are intended to help you get started cutting our most popular
self-adhesive lms quickly and correctly. You can change these settings and/or replace them with your own
presets.
Open an existing PRESET by pressing the LOAD button on the SPD/FOR screen (refer to FIG. 2.2.1). The eight
presets are split between two screens:
2.3 Presets
Fig. 2.3.1
Fig. 2.2.4
