MUSICSON DP SYSTEMS - Page 24


24
IMPORTANT! The manufacturer to obtain a linear response on the whole
system,asshownontheresponsecurves,includingthesubwooferresponse,
adjustsallgainlevels.

2. - MUTE: This button mutes thelowfrequencies way. When pushed, the
low frequencies are completely eliminated and the LED next to the button
lightsup.

3. - LIMITER (-20, -10, -5,0dB): This LED bar indicates the limiting
levelofthebasschannel.Anormalworkingmarginshouldmakethe–5dBLED
lightupor,inextremecases,lightupthered0dBLEDoccasionally.When
we have reached this level, the limiter circuits are starting to work in
ordertoprotectthespeakersfrompowersurges.

4. - LEVEL: This control adjusts the output gain for the midfrequency
way.Adjustabletovaluesbetween–12and+6dB.

IMPORTANT! The manufacturer to obtain a linear response on the whole
system,asshownontheresponsecurves,includingthesubwooferresponse,
adjustsallgainlevels.

5. - MUTE: This button mutes themidfrequencies way. When pushed, the
midwayiscompletelyeliminatedandtheLEDnexttoitlightsup.


6. - LIMITER (-20, -10, -5,0dB): This LED bar indicates the limiting
levelofthemidfrequencychannel.Anormalworkingmarginshouldmakethe
(–5)dB LED light up or, in extreme cases, light up the red 0 dB LED
occasionally. When we have reached this level, the limiter circuits are
startingtoworkinordertoprotectthespeakersfrompowersurges.

7.-LEVEL:Thiscontroladjuststheoutputgainforthehighfrequency
way.Adjustabletovaluesbetween–12and+6dB.

IMPORTANT! The manufacturer to obtain a linear response on the whole
system,asshownontheresponsecurves,includingthesubwooferresponse,
adjustsallgainlevels.

8.-MUTE:Thisbuttonmutesthehighfrequenciesway.Whenpushed,the
high frequency way iscompletely eliminated andtheLED next toitlights
up.

9. - LIMITER (-20, -10, -5,0dB): This LED bar indicates the limiting
levelofthehighfrequencieschannel.Anormalworkingmarginshouldmake
the –5 dB LED light up or, in extreme cases, light up the red 0 dB LED
occasionally. When we have reached this level, the limiter circuits are
startingtoworkinordertoprotectthespeakersfrompowersurges.


10. - HI-EQ: This control allows adjusting the response of the
compression driver within the highest frequencies. It can be adjusted
between10kHzand20kHz.

11.-ON:ThisLEDindicatesthattheprocessoristurnedON.

12.-POWER:Mainsswitchoftheprocessor.

ATTENTION! Inside these signal processors you can find a series of
adjustablecomponents.Itisofvitalimportancenottochangetheoriginal
settings,sinceamodificationofworkingthresholdsoroffsetvaluesofthe
