Mutable Instruments Clouds Illustrated Manual

Granular Processing: Inputs and outputs
All CV inputs are calibrated for a range of +/- 5V. Voltages outside of this range are
tolerated, but will be clamped.
1. FREEZE gate input. When the input gate signal is high, stops the recording of incom-
ing audio, just as latching the FREEZE button would do.
2. TRIGGER input. Generates a single grain. By moving the grain DENSITY to 12
o’clock, and sending a trigger to this input, Clouds can be controlled like a micro-sam-
ple player. An LFO or clock divider (or even a pressure plate) can thus be used to sow
grains at the rate of your choice.
3. 4. Grain POSITION and SIZE CV inputs.
5. Grain transposition (PITCH) CV input, with V/Oct response.
6. BLEND CV input. This CV input can control one of the following functions depending
on the active blending parameter: dry/wet balance, grain stereo spread, feedback
amount and reverb amount.
7. 8. Stereo audio input. When no patch cable is inserted in the right channel input, this
input will receive the signal from the left channel.
9. 10. Grain DENSITY and TEXTURE CV inputs.
11. 12. Stereo audio output.
