2205B0JE-DA-J-N_2014.05.

3–14–15 Botan Koto-ku, Tokyo 135-8482, Japan

Screw Compressor

J-Series Instruction Manual

170JS-V/170JM-V/170JL-V

220JS-V/220JM-V/220JL-V

280JS-V/280JM-V/280JL-V

CAUTION

Before operating, maintaining, or inspecting this product, read the manual thoroughly and fully

understand the contents.

Keep the operation manual in a safe, designated place for future reference whenever the need

arises.

Specifications of this product are subject to change without prior notice.

Table of Contents

Other manuals for mycom 170JL-V

Operation Manual20 pages

Questions and Answers:

M
Mr. David DaltonAug 16, 2025
What causes abnormally high pressure in my mycom 170JL-V?
- A
  Amber RobertsAug 17, 2025
  Abnormally high pressure in your mycom Air Compressor can be caused by a heat exchange failure at the condenser (heat exchanger). Clean and wash the heat exchangers, using solvent depending on the contamination. Other causes include malfunction of the fan motor, thermo-switch, water spray bars, cooling water pumps, etc. (identify malfunctioning devices, examine their causes, take measures, and replace malfunctioning devices), a flow volume adjustment fault for cooling water, brine, etc. (readjust manually or examine the cause and take measures if an automatic control valve is used), or poor performance in the heat exchanger (re-examine the conditions to improve if the trouble is caused by a change in operating conditions).
M
Michael LeonardAug 20, 2025
What to do if my mycom Air Compressor stops immediately after startup?
- G
  Gina MurrayAug 20, 2025
  If your mycom Air Compressor stops immediately after startup, it could be due to the low pressure protection circuit being activated. Check for and stop any refrigerant leaks, then replenish the refrigerant, being aware of potential moisture contamination in the system. Another cause might be insufficient refrigerant circulation volume; if there are any heat exchange failures, such as poor defrost performance, investigate the cause and take corrective actions. A malfunction of the low pressure protection device, pressure sensor, relays, etc., could also be the reason. In this case, identify the malfunctioning devices, examine their causes, take appropriate measures, and then replace the faulty devices.
W
William JacksonAug 31, 2025
What causes faulty indication of capacity control position in my mycom Air Compressor?
- S
  Sarah LambertAug 31, 2025
  Faulty indication of capacity control position in your mycom Air Compressor may arise from imprecision in the compressor indicator. Manually tighten screws to the 0% indication position of compressor capacity control. It could also be due to imprecision in the controller capacity control indicator, in which case, replace the indicator cam. Another potential cause is a malfunction in the potentiometer; if this is caused by aging degradation or prolonged partial load operation, replace the potentiometer.
A
April GlennSep 4, 2025
What causes capacity control malfunction in my mycom Air Compressor?
- A
  Andrew DavisSep 4, 2025
  Capacity control malfunction in your mycom Air Compressor can occur if 100% or 0% is undetected by the indicator; replace the micro-switch in this case. Malfunction of solenoid (modular) valves or related relays for capacity control can also cause this issue; for aging degradation, replace the parts. Internal leakage of solenoid (modular) valves for capacity control is another possibility; if caused by prolonged low load operation, improve by re-examining the operation method.
B
belinda73Sep 8, 2025
How to address abnormal vibration and/or noise in my mycom 170JL-V Air Compressor?
- A
  Anne BanksSep 8, 2025
  Abnormal vibration or noise in your mycom Air Compressor might be due to insufficient axis adjustment with the motor side; readjust the shaft-center. Another cause could be a large runout in the Male rotor axis; if loose locknuts exist and no other fault is found in parts such as the thrust bearing, tighten the locknuts evenly. Damage to the thrust bearing can also result in abnormal vibration or noise. Note that the appropriate time for replacement will differ due to operating conditions.

mycom 170JL-V Specifications

General

Brand	mycom
Model	170JL-V
Category	Air Compressor
Language	English

Summary

Important Information

Important Information for Safe Use of This Product

Crucial safety guidelines and precautions for operating the product.

Safety

Safety Devices

Details on emergency stop buttons and protection devices.

Structure and Specifications of the Compressor

Compressor Specifications

Variable Vi Control

Installation

Precautions for Installation

Essential safety and preparatory steps before installation.

Compressor and Package Operation

Lubricant (Refrigerant Oil)

Maintenance and Inspection

Disassembly and Assembly of the Compressor

Detailed instructions for disassembling and reassembling compressor parts.

Troubleshooting

Compressor Not Starting Troubleshooting

Tips for Design, Manufacturing, and Installation of the Compressor Package

Precautions for Design of the Compressor Package

Tips for Compressor Package Installation
