mycom 200LUD User Manual

Chapter 5 Maintenance and Inspection
UD-series Screw Compressor 5.4 Disassembly and Inspection
5-31
Thrust Bearing (1) Thrust Bearing (2)
e)
Remove the thrust bearing alignment spacers from the rotor.
Thrust bearing alignment spacer（1） Thrust bearing alignment spacer（2）
Cut-out part for Shaft Key
Tilting pad thrust bearing (TPTB)
Lock pin
