mycom 320SUD

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 200*UD
7-17
P/N
Part Name
Code No.
Remarks
Q’ty.
34 Set Screw NA83608-015 M8X15 2
35 O-ring PA11-120 JISB2401 1A P120 1
36 Spacer CS03600-200 200*** 1
37 Stop Ring NG11-130 H130 2
38 Thrust Bearing CS03800-200P 7313PPS 2
38 Ductile retainer
CS03800-200 NSK type
CS03800-200N NTN type
39 Lock Nut NG31-013 AN13 2
40 Lock Washer NG32-013 AW13 2
41 Spacer, Thrust Bearing Outer Race CS04100-200 200*** 2
42 Spacer, Thrust Bearing Alignment CS04200-200 200*** 2
43 Thrust Bearing Gland CS04300-200 200*** 2
45 Hexagon Head Bolt NB111012-035 M12X35 8
46 Conical Spring Washer ND150-012 M12 8
46 Lock Washer Set (old , plate type) CS0469-E 200*** 8ps/set -
48 Retainer, Oil Seal CS04800-200VDS 200V** BOS TYPE 1
49 O-ring PA12-115 JISB2401 1A G115 1
50 Oil Seal CS05010-200VD SA1J 65X85X12 1
51 Seal Cover CS05100-200BBS 200*** 1
51 Seal Cover CS05100-200UV4 200*** 1
51
H
E
Seal Cover CS05100-200HE 200*** (HE) 1
52
Gasket, Seal Cover
CS05200-200N
200***
1
53
Hexagon Socket Head Cap Screw
NB35410-025
M10X25
8
54
L
Unloader Slide Valve (L Port)
CS05400-200SDL
200S**
1 (S**)
54
M
Unloader Slide Valve (M Port)
CS05400-200SDM
200S**
1 (S**)
54
H
Unloader Slide Valve (H Port)
CS05400-200SDH
200S**
1 (S**)
54
L
Unloader Slide Valve (L Port)
CS05400-200MDL
200M**
1 (M**)
54
M
Unloader Slide Valve (M Port)
CS05400-200MDM
200M**
1 (M**)
54
H
Unloader Slide Valve (H Port)
CS05400-200MDH
200M**
1 (M**)
54
L
Unloader Slide Valve (L Port)
CS05400-200LDL
200L**
1 (L**)
54
M
Unloader Slide Valve (M Port)
CS05400-200LDM
200L**
1 (L**)
54
H
Unloader Slide Valve (H Port)
CS05400-200LDH
200L**
1 (L**)
55 Unloader Slide Valve - 200S** 1 (S**)
55 Unloader Slide Valve - 200M** 1 (M**)
55 Unloader Slide Valve - 200L** 1 (L**)
58 Hexagon Socket Head Cap Screw NB35410-030 M10X30 4
59 O-ring PA11-040 JISB2401 1A P40 2
60 Unloader Cylinder CS06000-200S 200S** 1 (S**)
60 Unloader Cylinder CS06000-200M 200M** 1 (M**)
60 Unloader Cylinder CS06000-200L 200L** 1 (L**)
61 Hexagon Socket Head Cap Screw NB35412-030 M12X30 2
62 Hexagon Socket Head Cap Screw NB35412-075 M12X75 6
63 O-ring PA12-150 JISB2401 1A G150 1
64 Unloader Piston CS06400-200D 200*** 1
65 O-ring PA11-125 JISB2401 1A P125 1
66 Cap Seal CS06600-200-1 CAP-3BE125 1
67 Push Rod, Unloader Slide Valve CS0671-ES 200S** 1 (S**)
67 Push Rod, Unloader Slide Valve CS0671-EM 200M** 1 (M**)
67 Push Rod, Unloader Slide Valve CS0671-EL 200L** 1 (L**)
