mycom 320SUD

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 250*UD
7-22
P/N
Part Name
Code No.
Remarks
Q’ty.
67 Push Rod, Unloader Slide Valve CS0671-FL 250L** 1 (L**)
68 Guide Pin NE2505-012 φ5X12 1
69 Lock Nut NG31-008 AN08 2
70 Lock Washer NG32-008 AW08 2
73 O-ring PA12-035 JISB2401 1A G35 1
74 Unloader Cylinder Cover CS07400-250S 250*** 1
75 O-ring PA12-170 JISB2401 1A G170 1
76 Hexagon Socket Head Cap Screw NB35412-030 M12X30 8
77 Indicator Cam CS07700-250S 250S** 1 (S**)
77 Indicator Cam CS07700-250M 250M** 1 (M**)
77 Indicator Cam CS07700-250L 250L** 1 (L**)
78 Ball Bearing CS07800-200 #6000 1
79 Stop Ring NG12-010 S10 1
80 Bearing Gland CS08000-200 200*** 1
81 Hexagon Socket Head Cap Screw NB35406-015 M6×15 3
82 V-ring CS08200-200B VH10 NBR 1
82 V-ring CS08200-200V VH1- FPM 1
83 Spring CS08300-200 200*** 1
84 Retainer, Indicator Cam Spring CS08400-200 200*** 1
85
Oil Injection Pipe
CS08500-250SD
250S**
1 (S**)
85 Oil Injection Pipe CS08500-250MD 250M** 1 (M**)
85 Oil Injection Pipe CS08500-250LD 250L** 1 (L**)
87 Guide Block CS08700-250 250*** 1
88 Stem, Guide Block
89 O-ring PA11-020 JISB2401 1A P20 2
91 Shaft Key CS09100-250 250*** 1
92 Suction Cover Flange without hole CS71400-P250 MYK250A Male 1
93 Gasket,Suction Flange CS09300-250N MYK250A 1
94 Hexagon Head Bolt NB12024-065 M24X65 12
95 Discharge Cover Flange CS71400-P150CD MYK150CD Male 1 (*UD)
96 Gasket, Discharge Flange CR72000-150N MYK150A 1
97 Hexagon Head Bolt NB12022-055 M22X55 8
97 Hexagon Head Bolt NB12022-085 M22X85 8 (*UD)
98 Spring Pin NE3203-012 φ3×12 2
100 Mechanical Seal Assembly (BOS) CS10000-250BE 250V** BOS Type 1
100 Mechanical Seal Assembly (BBSE) CS10002-250EBS BBS-E 1
100 Mechanical Seal Assembly (UV4) CS10009-250-F70 UV4
100 Mechanical Seal Assembly (BBS3) CS10001-250BBS BBS3 1
120 Unloader Indicator Assembly (With dial)
CS120-IND062WP-
UP
1
120 Unloader Indicator Assembly (No dial) CS120-IND062WP 200, 0-50 % 1
125 Micro Switch CS12501-IND06P 200*** Z15GW 2
129 Potentiometer 200-1k CS12900-IND06P with lead wire 1
129 Conductive Potentiometer 200-1k CS12919-E10 with lead wire 1
164 Retainer, Oil Injection Pipe CS16400-250 250*** 1
166 Hexagon Socket Head Cap Screw NB35405-012 M5X12 2
215
1
Flange with hole, Lubrication Oil Supply CR74000-025 MYK25A Male 1
