Chapter 1 Safety
Screw Compressor i-series 1.3 Residual Risks
1-5
Hazardous
sources
Predicted hazard
Measures to be taken
in operation
Countermeasures in
cleaning, inspection,
and parts replacement
I
Package Unit
Electric
components in
each part (oil
heater,
protective
device, etc.)
 Electric shock caused by
contact with live wires or
electrical leakage
 Pinched due to contact
with driving part
 Install protective
cover on terminals,
and prohibit
opening.
 Keep away and do
not touch.
 Wear protective
gear.
 Turn off each
breaker and the
control power, and
conduct
lockout/tagout.
 Wear protective
gear.
J
Package Unit
Oil drain
 Contact with hazardous
substances generated by
leakage or spout
 Burn caused by contact
with high-temperature
fluid
 Sufficient ventilation
 Keep away and do
not touch.
 Wear protective
gear.
 Sufficient ventilation
 Wear protective
gear.
 Work at a
temperature of not
higher than 40°C.
K
Noises
 Damage caused by noise
 Wear protective
gear.
—
i125L with Spacer for NEMA i160L with Spacer for NEMA
(example) (example)
Figure 1-1 Locations of Hazardous sources (Compressor)
