Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.3
Compressor Specifications
2-2
2.3 Compressor Specifications
2.3.1 Standard Specifications
Table 2-1 Specifications of i-series Compressor
Items
Flange motor connection
NEMA — 3**C, 40*C 3**D, 4**D
IEC — FF400 FF500 FF500 / FF600
Product mass (Compressor only)
kg
330 350 520 560 600
Mass of
compressor with
motor spacer
for NEMA
kg
490 510 670 710 750
for
IEC
Standard speed 50Hz/60Hz min
-1
2950/3550
Rotation direction — Clockwise as viewed from motor
Swept volume 50Hz/60Hz
CFM 116/139 174/210 244/294 305/367 366/441
Refrigerant
—
R717 / R404A / R507A / R134a
Design pressure *Note MPa
2.6
(Applies to i-series compressors manufactured
and shipped in May 2014 or after.)
Capacity control — 3-step (100%, 75%, 50%) unloader
Connected
pipe size
Suction flange —
MYCOM 100A (4")
ANSI ＃300 5"
Discharge flange
—
MYCOM 65ACD ANSI ＃300 3"
Oil inlet port
— Rc1/2 MYCOM 65A
Economizer — Rc3/8 Rc3/4
Aquamizer
(Liquid injection)
Unless otherwise noted, the pressure unit MPa represents the gauge pressure in this manual.
For limits of working temperature and pressure, see Section 2.3.2 "Operation Limits" in this
Chapter.
*Note: The design pressure varies according to each area, laws and ordinances of the country.
The design pressure of this list is the maximum value of the compressor. Therefore, the
real design pressure may become less than this value according to the law.
Please confirm real pressure on a name plate and individual specifications.
