2203M4-JE-MY-iS2-N_2017.04.
Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.3
Compressor Specifications
2-13
Figure
2-9 i160M Outer Dimensions with a Spacer for Motor Flange (IEC FF500)
