mycom i160M

2203M4-JE-MY-iS2-N_2017.04.
Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.4
Configuration of Compressor
2-26
2.4.3 Parts Configuration Table
Table 2-4 i125S/L Parts Configuration Table
P/N Part name Code No. Remarks Qty
1
Main Rotor Casing
－
i125S-* port
S:1
1
Main Rotor Casing
－
i125L-* port
L:1
2-1 Hexagon Socket Head Cap Screw NB35412-050 M12×50 SCM435 45
2-2
Hexagon Socket Head Cap Screw
NB35412-035
M12×35 SCM435
39
3
Alignment Pin NE242A13-050A
Φ13×50 with internal thread
and slot
4
3
Alignment Pin NE242A13-050A
Φ13×50 with internal
thread and slot for Motor
Spacer
2
4-1
Eye Bolt
NB600-16
M16
3
4-2
Eye Bolt
NB600-20
M20
1
4-3
Eye Bolt
NB600-30
M30
1
5-1
Suction Adapter
－
i125
1
5-2
Strainer Cover
CS00510-I125
i125
1
6-1
Gasket, Suction Adapter
CS00600-I125
i125 t=0.5
1
6-2
Gasket, Strainer Cover
CS00900-I125
i125 t=0.5
1
7
O-ring
PA12-140
JIS B 2401 G140
1
10-1
Hexagon Socket Head Cap Plug
NF06-004
R1/8 S45C
5
10-2
Hexagon Socket Head Cap Plug
NF06-008
R1/4 S45C
10
10-3
Hexagon Socket Head Cap Plug
NF06-010
R3/8 S45C
S:6 L:5
10-4
Hexagon Socket Head Cap Plug
NF06-015
R1/2 S45C
1
11
Bearing Head
CS01100-I125
i125
1
12
Gasket, Bearing Head
CS01200-I125
i125 t=0.5
1
16
Bearing Cover
－
i125
1
17
Gasket, Bearing Cover
CS01700-I125
i125 t=0.5
1
18-1
Hexagon Socket Head Cap Screw
NB35416-055
M16×55 SCM435
7
20
Spring Pin
NE3203-008
Φ3×8
1
22
End Cover
CS02200-I125
i125
1
23
Gasket, End Cover
CS02300-I125
i125 t=1.0
1
25
Male Rotor
－
i125SM/SF FCD S:1set
26
Female Rotor
－
25
Male Rotor
CS02500-I125L
(M,F ASSY)
i125LM/LF FCD L:1set
26
Female Rotor
27-1
Radial Bearing
CS02800-FM125M
NU2308ET7
2
27-2
Radial Bearing
CS02800-FM125F
NU2309ET7
2
29-1
Snap Ring
NG11-090
H90 C type-Internal
1
29-2
Snap Ring
NG11-100
H100 C type-Internal
1
29-3
Snap Ring
NG12-040
S40 C type-External
1
30
Balance Piston
CS03000-I125
i125
1
31
Slotted Set Screw
NA14708-016
FM160 (M8×16)
1
32
Snap Ring
NG12-045
S45 C type-External
1
