Myron L ULTRAPEN PT2 User Manual

4 5
II. Routine Maintenance
1. ALWAYS rinse the pH sensor with clean water after each use.
2. ALWAYS replace the soaker cap halflledwithpHSensorStorageSolutionto
prevent the sensor from drying out after each use.
3. If the sensor becomes dirty, clean the sensor surface with an isopropyl soaked
cotton swab. Then rinse thoroughly with clean water.
4. Do not drop, throw or otherwise strike the pen. This voids the warranty.
5. Do not store the pen in a location where the ambient temperatures exceed its
speciedOperating/StorageTemperaturelimits.
III. pH Sensor Replacement (Follow the instructions that come with your Replacement Sensor.)
CAUTION:OnlyRemove/ReplacethepHsensorinaCLEANandDRYenvironment!
To remove the pH sensor:Removethesoakercap;makesurethePT2(includingthe
pH sensor) is clean and dry. Loosen the battery tray (toallowpressureequalization).
ThenrmlygraspthepHsensorbodyandslowlypullthepHsensorout.
To install a new pH sensor: Line up the alignment tabs on the pH sensor with the
alignment slots on the PT2 unit. Gently push the pH sensor into position, then
close the battery cap.
ACCESSORIES
STANDARD SOLUTIONS FOR CALIBRATION:
TheULTRAPEN™PT2requirespH4,pH7,andpH10buffersolutionsforwet
calibration and pH Sensor Storage Solution for proper storage.
Order MODEL#s: PH4, PH7, PH10, and PHSS
ReplacementpHSensor(withinstructions)—OrderModel:RPT2
MYRON L WARRANTY
ThePT2,excludingthepHsensor,hasaone(1)yearlimitedwarranty.
ThepHsensorhasasix(6)monthlimitedwarranty.
PT2OM 08-13
SPECIFICATIONS
pH Temperature
Range: 0.00-14.00pH 0-71°C/32-160°F
Accuracy: ±0.01pH(AfterWetCalibration) ±0.1ºC/±0.1ºF
Repeatability: ± 0.01pH ±0.1ºC/±0.1ºF
Resolution: 0.01pH 0.1ºC/0.1ºF
TimetoReadingStabilization:10-30seconds
Power Consumption: Active Mode 37mA, Sleep Mode 2µA
Temperature Compensation: Automatic to 25ºC
Physical Dimensions: 17.15cm L x 1.59cm D or 6.75in. L x 0.625in. D
Weight:54g/1.9oz.(withoutsoakercapandlanyard)
CaseMaterial:AnodizedAircraftAluminumwithProtectiveCoating
Battery Type: N type, Alkaline, 1.5V
Calibration Solutions: pH4, pH7, pH10
Operating/StorageTemperature:0-55ºCor32-131ºF
Enclosure Ratings: IP67 and NEMA6
EN61236-1: 2006 – Annex A: 2008: Electrostatic discharge to case of instrument may
cause PT2 to spontaneously power on. If this happens, the PT2 will power itself off
within seconds.
QUICK REFERENCE INSTRUCTIONS
1. Push and release the push button to turn the pen on.
2. WhiletheLEDashesrapidly,dipthepeninsamplesolutionsothatthesensor
is completely submerged.
3. WhileLEDashesslowly,swirlpenaroundtoremovebubbles,keepingthesensor
submerged.Avoidcontactwithsides/bottomofcontainer,ifapplicable.
If in LIVE mode,whiletheLEDisashingslowly,thedisplaywillalternatebetween
the live pH and temperature readings. Note readings for your records.
If in Hold mode, when the LED turns on solid, remove the pen from the solution.
The display will alternate between the captured pH and temperature readings.
Note readings for your records.
MYRON L COMPANY
2450 Impala Drive
Carlsbad, Ca 92010-7226
Phone: +1-760-438-2021
Customer Service E-Mail: info@myronl.com
TechnicalSupportE-Mail:techquestions@myronl.com
Website: www.myronl.com
MADE IN USA ©2012 MYRON L COMPANY
Cannon Water Technology Inc.
233 Technology Way Suite 9, Rocklin, CA 95765
Voice: 1 916-315-2691, FAX: 1 916-304-0210
csd@cannonwater.com, https://cannonwater.com/
