MZ electronic KOMPASS2 User Manual

KOMPASS2, KOMPASS4 - 4 - Rev. 07 – 2015
English
Description
The 2/4 channels radio-control units allow windlass or thrusters operation.
Technical Data
Transmitter
Power supply 2 batteries 1.5V type AAA
Frequency 433.92MHz
Protection rating IP66
Operative temperature 0 / +70 °C (32 / 158 °F)
Dimensions (mm) 52 x 98 x 26
Weight (g) 85
Receiver
Power supply from 10 to 30 V DC
Frequency 433.92MHz
Protection rating IP65
Operative temperature 0 / +70 °C (32 / 158 °F)
Dimensions (mm) 150 x 57 x 32
Weight (g) 100
Maximum load for every output at 30Vdc 3A
* excluding cable connection zone
Warning
CONNECT ONLY TO A DC POWER SUPPLY.
General Notes
The 2/4 channels radio-control must be used solely for the purposes described herein. Any other use is to be considered improper.
Any tampering with the instrument will result in immediate voiding of the warranty.
Components
The package contains:
• 2 or 4 channels radio control unit (transmitter and receiver are already programmed in order to work together). Transmitter is
already supplied with 1.5V AAA alkaline batteries.
• Adhesive label for thrusters and windlass function
• Support kit for the transmitter and 4 screws 3.5x13mm for RX and TX fastening.
• Instructions for use
In case of metallic walls or any obstacle to radio signal, it is possible to buy as an optional an external antenna, that is not included in the
packaging; please refer to the manual for connections.
Installation
(see connection diagram)
Warning
ALWAYS DISCONNECT THE BATTERY PRIOR THE INSTALLATION.
• If possible mount the receiver a long way from big metal masses or electric motor or windlass.
• For the electric connections see the wiring diagram
• After connection, check that all work properly;
• Place the adhesive label on the transmitter according to the desired function (windlass or thruster).
Transmitter’s Functioning
• Press ON button for about 2 seconds. The intermittent led turns on the transmitter;
• The led blinks slowly whenever the transmitter isn’t transmitting, I and it is turned on steady when any operation button is pressed;
• Whenever the button is released operation stops and led blinks again;
• Passing from one button to the opposite one (Up ↔ Down or Left ↔ Right) has a standard 1.5 sec. delay; simultaneous use of
non opposite buttons is allowed (Up+Left, Up+Right, Down+Left, Down+Right in 4 channels radio control unit);
• Transmitter automatically turns off 120 seconds after the last command has been given;
