Disposal
10
Disposal
The table below shows the materials of ALLUX
TM
knee unit in each
component. When disposing of ALLUX
TM
, comply with the rules
stipulated in the local community. If you return it to Nabtesco after
giving such a notification,we will dispose of it for you.
9
4
3
8
6
9
5
1
7
2
10
28
ALLUX
TM
User’s Guide
Part name Classification of material Remarks
1. Frame Plastic
Carbon fiber reinforced
composite material.
Aluminum structural parts are
inserted in it.
2. Knee links Metal Aluminum alloy
3. Knee pad Rubber
4. Stopper rubber Rubber
5. Hydraulic cylinder Metal
Body: aluminum alloy, piston
rod: titanium alloy, o-ring:
rubber,
6. Microprocessor control board Electronic component
Electronic substrates and
component chips comply with
the RoHS directive.
7. Lead wire Electric wire
8. Battery Li-ion battery See 8.1
9. Joint parts Metal Titanium alloy
10. Cover, etc. Plastic, rubber
Refer to each material symbol
on each.
