10 LAN
• LAN connection must be setup for wired connection to be
established. Set up a Wired Ethernet broadband router with
broadband internet connection. Your router or home network
should have a built-in DHCP server to consummate the connection.
• Using a standard straight-through Ethernet cable (not supplied),
connect one end of the Ethernet cable to the LAN port of your wired
Ethernet broadband router and the other end to D 7050’s LAN port.
11 DOCK
• Applicable for direct playback only of iOS device. Using applicable
Apple USB connector, connect your iOS device to this input.
• Allow direct charging of smartphone or android devices using
applicable connector (not supplied)
12 COMPUTER
• Asynchronous USB 24 bit/96 kHz input assures lowest jitter for best
musical performance.
• Using Type A to Type B cable connector (not supplied), interface
computer audio to this asynchronous Type B USB input to directly
stream 24/96 PCM content from your PC or MAC.
• Ensure that the Sound or Audio device setting of your computer is
set to “NAD USB Audio”.
MINIMUM PC SYSTEM REQUIREMENT
Microsoft Windows XP Service Pack 2 or higher, Microsoft Windows 7
FOR MAC USERS
Minimum Mac OS X Snow Leopard (version 10.6) and later versions
NOTE
Download and install to your PC the NAD USB Audio driver from the
Manuals/Downloads tab of the NAD web address http://nadelectronics.
com/products/digital-music/D-7050-Direct-Digital-Network-Amplier.
13 DIGITAL AUDIO INPUT
(COAXIAL1, COAXIAL 2, OPTICAL1, OPTICAL 2)
• Connect to the corresponding optical or coaxial digital output of
sources such as CD or BD/DVD players, digital cable box, digital
tuners and other applicable components.
IMPORTANT NOTE
The digital audio input is 24/192 capable and can accept PCM audio
signal only. Ensure that the digital audio output of your source is set to
PCM before connecting to the digital audio input of D7050.
14 SPEAKERS
• Connect the right speaker to the terminals marked “R +” and “R-”
ensuring that the “R+” is connected to the “+” terminal on your
loudspeaker and the “R-” is connected to the loudspeaker’s “-”
terminal. Connect the left speaker to the terminals marked “L +”
and “L-” ensuring that the “L+” is connected to the “+” terminal on
your loudspeaker and the “L-” is connected to the loudspeaker’s “-”
terminal.
15 AC MAINS INPUT
• The D 7050 comes supplied with a separate detachable mains
power cord. Before connecting the plug to the mains power source,
ensure that it is rmly connected to the D 7050’s AC Mains input
socket rst.
• Always disconnect the mains power plug from the mains power
source rst, before disconnecting the cable from the D 7050’s AC
Mains input socket.
IDENTIFICATION OF CONTROLS
6
