NAD 906 - Exploded Parts List; Component Breakdown and Part Numbers

EXPLODED PARTS LIST
PART NO.
9541215000
9541003200
9547137500
9547137700
5547137600
5547138000
9947137900
9545309600
9945309700
9947137800
9547533100
9542226100
9541539000 |
9547530460
9547501200
9947802120
99453069 10
9547528700
9940100200
7190550003
7033161156
7001120216
7101200302
7076170012
7001170612
7033161152
7033161452
7033251652
7000305022
7033160652
7006171612
DESCRIPTION
FRONT PANEL
TOP COVER
CHASSIS
BACK PLATE
TRS. BRACKET
FRAME (R)
FRAME (L)
HEAT SINK
HEAT SINK P |
HEAT SINK BRACKET
POWER SW, BRACKET
~POWER BEZEL
PUSH BUTTON
HOLDER-PCB
CORD BUSHING
RUBBER FOOT
HEAT SINK S
TRANSISTOR WASHER
WIRE CLAMP
MACHINE SCREW M4.0x6 W/W Zn-BLK
TAPPING SCREW M3x8 Zn-BLK
MACHINE SCREW M2.5x4 Zn-BLK
WASHER TOOTH LOCK M3.0, Zn
NUT M3.0 Zn — |
MACHINE SCREW M3.0x6 Zn
TAPPING SCREW M3.0x8 TS2 Zn
TAPPING SCREW M3.0x10 TS2 Zn
TAPPING SCREW M3.0x12 TS2 Zn
TAPPING SCREW M3.0x10 W/W TS2 Zn
TAPPING SCREW M3.0x6 TS2 Zn
MACHINE SCREW M3.0x12 W/SPW Zn
13
