VIDEO OUTPUT SCAN TYPES (EUROPEAN)
VIDEO OUTPUT SCAN TYPES (NORTH AMERICAN)
HIGH RESOLUTION DVD-AUDIO STEREO 192KHZ 24-BIT DISCS
When playing 192KHz 24-bit High resolution DVD-audio stereo discs through the MIXED AUDIO OUT,
it is necessary to select the option 192 kHz HDMI in the Digital Audio Output OSD menu.
Please note: Do not forget to revert this setting to 48kHz or 96kHz for normal playback of other types
of media.
DIGITAL OUT (COAXIAL AND OPTICAL) VERSUS MEDIA FORMAT
NOTES
Reference
480I/576I 480P/576P 720P 1080I
HDMI
VGA
Component
YPbPr
Component
YCbCr
CVBS
S-Video
SCART/RGB
480I/576I 480P/576P 720P 1080I
HDMI
VGA
Component
YPbPr
Component
YCbCr
CVBS
S-Video
DVD-Audio
(96 kHz/24-bit)
DVD-LPCM
(48/96 kHz)
Dolby
Digital
DTS CD
48 kHz
96 kHz
192 kHz
Digital Audio
Output
Stream / PCM
PCM
48 KHz
Sample Freq.
DOLBY
DIGITAL
/ PCM
96 KHz
192 Khz HDMI
5.1 Speaker
Setup
DRC
Test Tone
Master Volume
Downmix
