NAD M55 - Page 11

(P/N:70-051009-0)
Sleeve 4PCS
(P/N:14-55505-10)
5Pin Wire
XY-A33Loader
(P/N:36-00033-00)
Rail 2PCS
(P/N:70-067004-0)
Screw 4PCS
(
P/N
:
61-
023208-
0)
FFC Folded with Tape
(P/N: see chart)
Screw 4PCS
(P/N:61-083506-0)
New Style DVD Door
(P/N:J70-051021-0)
New XY-A33 Loader and Rail A ssembly, Part Number 02-55598-00 for the M55
(may include either J36-00313-00 or J37-00313-00 traverse)
New Spare Part Door
part of kit #02-55598-00.
New Style DVD Door
(P/N:J70-051021-0)
Door Clamps and
Door Clamp Screws
P/N 66-051002-0 &
63-023504-1. Part of
kit # 02-55598-00.
New 5Pin Wire (P/N:14-55505-10) For XY-A33 Loader
NOTE: Connector at the loader end is reversed from Decoder end.
(part of kit #02-55598-00)
Height Adjustment Spacers 4PCS
(
P/N
:63-110603-0
)
Remove Line Clamp
Remove Standoffs
Quantity Comments
1 without traverse
4 attached to loader
2 attached to loader
1 attached to loader
2 attached to loader
2 attached to loader
1 attached to loader
4 powder coated
4 use to fine adjust height
4 machine screw black
1 210mm M5 folded 96°
1 180mm M55 folded 96°
2+1 R477 & R478 (1 extra)
1 traverse to decoder board
*M5 FFC with tape 195mm folded 96° part number 14-50524-30
6Pin Wire short 14-55506-11
FFC M5 with Tape
FFC M55 with Tape
14-50524-10*
14-55524-30
4.7 ohm SMD 07-90479-00
14-55505-10
66-051002-0
63-023504-1
J70-051021-0
Height Adjustment Spacers 63-110603-0
XY-A33Loader
61-023208-0
70-067004-0
36-00033-00
5Pin Wire M5 & M55
Door Clamp
Door Clamp Screws
DVD Door
(complement of parts)
New XY-A33 Loader and Rail Assembly, Part Number 02-55598-00
Rail Screws 61-083506-0
Description Part Number
Loader Screws
Rail Black
Sleeve Black 70-051009-0
2-5
2-6
