NAD M55 - Section 4 Mechanism (original type); Mechanism Assembly Overview

SECTION 4 MECHANISM (original type)
Mechanism Assembly (36-55313-00) NLA
Laser Pick Up
J37-00313-00
Rubber Damper
Screw
Loader WXD-8836B
Loader Gasket
(79-051002-0)
Loader Clamp2 (optional)
(69-051004-0)
Loader Clamp1 (optional)
(69-051003-0)
4-1
New "Toothed"
Loader Belt
(79-051014-0)
NSP
Original 5Pin Wire (P/N:14-55505-00) For original WXD-8836B Loader
NOTE: Connector at the loader end is same side as Decoder end.
