Nagano Keiki GS5 User Manual

TY1－3A 4／18
Rev.
2
[Definition of Safety Terms]
Safety precaution in this manual are classified as follows:
Ignoring this warning can cause serious injury or even death.
Ignoring this warning can cause an injury or even death.
Ignoring this warning can cause the material damage and the defectiveness of instrument
performance.
2. SPECIFICATIONS
(1) Pressure Ranges
(2) Performances
(The table below shows the classification specified in JIS B 7505-1.)
Unit : %
Accuracy class
Tolerance
*2
Range of scale A
Range of scale B
Class 1.6
±1.6
±2.4
Notes (*2) The value of tolerance shall be expressed by percentage to the pressure span.
Size Shape of case *1 Connection Pressure ranges
60DIA.
A,B,D
G1/4B,R1/4
0～0.1MPa → 0～25MPa
－0.1～0MPa → －0.1～2.5MPa
75DIA.
A,B,D
G1/4B, G3/8B
R3/8
0～0.1MPa → 0～40MPa
－0.1～0MPa → －0.1～2.5MPa
100DIA.
A,B,D
G3/8B,G1/2B
R3/8,R1/2
0～0.1MPa → 0～40MPa
－0.1～0MPa → －0.1～2.5MPa
WARNING
CAUTION
DANGER
