Nagman 650-H User Manual

NAG/IM/650-H/01/22 21
8. TROUBLESHOOTING / MAINTENANCE
Replace the main fuse by following the below
instructions:
 Identify the main fuse in the fuse box in the socket.
 Open the lid of the fuse box using a screwdriver.
 Replace the fuse with the main fuse rating 6.3A (12A
for 115V).
 Controller is not ON, check the control fuse.
 Fan is not working check the Transformer fuse.
Replace the Heater fuse by following the below
instructions:
 Identify the heater fuse in the corresponding fuse
holders marked in the enclosure of the equipment.
 Open the fuse holder in anti-clockwise direction.
 Replace the fuse with the main fuse rating as 6.3A
(12A for 115V)
