NAIM CD5 - ISSUE 2 - CD5 Rear Panel and Connections; CD5 to Flatcap 2 Power Supply

13
CD5
ch1
out
-ve
nc
nc
ch 2
out
CD5 Output
12.1 CD5 Rear
12.2 CD5 Connected to Flatcap 2 Power Supply
to preamplifier
mains inputpower
link plug fitted
RC5 input
Note
The RC5 input fitted to the CD5 is intended to accept external control
signals for multi-room applications. Contact your dealer for further
information on its use.
The CD5 features various technologies to reduce microphonic effects, in
particular a compliant mounting for the main circuit boards and the DIN
sockets on the rear. Some movement of the board and sockets when
connecting/disconnecting is normal.
mains inputpower
link plug removed
mains inputpower
Flatcap 2
CD5
cable
direction
marker
240° 5 to 5 pin DIN
180° 5 to 5 pin DIN
Interconnect Cables
