Service LED Indication Fault Indicated
Credit dispense pulse remains on
Service switch remains on
Mouth micro switch remains on
Hopper test switch remains on
Hopper microswitch remains on
Hopper not dispensed
Tickets run out
Ticket count switch remains on
Test switch remains on
Opto 3 remains on
Opto 2 remains on
Opto 1 remains on
Mouth motor not working
Count Lamp Indication Fault Indicated
Mouth does not return to start position at
power-up
Godzilla does not return to start position
at power-up
6. TROUBLESHOOTING
The game constantly monitors certain functions and if there is a failure certain LEDs
or count lamps light as an indication.
The following table indicates these conditions.
Lamp OFF
Lamp ON
7
