Upgrade Kit Manual
RAVE RACER”
CENTER SWITCH 1 OFF
SWITCH 2 OFF
(d)
SERVICE OFF
COIN
OFF
VlEWSW OFF
@I
(0
(g),
EXIT -STEP ON THE GAS AND BRAKE
.
L J
Figure 9: Switch Test Screen
(a)
Verify
+,
-
full-scale readings and “OK” status in both CW (right) and
CCW (left) directions.
(b)
Verify + full-scale reading and “OK” status for full
defelection
of the gas
pedal.
(cl
Verify
+full-scale
reading and “OK” status for full deflection of the brake
pedal.
(d)
Verify ON/OFF and CENTER/UP/DOWN status.
(e)
Verify ON/OFF status.
(0
Verify ON/OFF status.
63)
Verify ON/OFF status.
12
To Next Page
