RIDGE RACER
2-
RAVE RACER”
Upgrade Kit Manual
E.
MONITOR TEST SCREENS
Use shifter, steering and /or gas pedal to toggle through the TEST screens.
Coior Bars
Crosshatch,
Green
Crosshatch,
White
White (high)
Window
White (med)
Window
White (low)
Window
Interlace Test
Green Cross
Bar
White Cross Bar
White Screen
Explanation
Fr3Ur
(4)
bERS-(Giii,
Red, Blue,
'$:ht
ffOrn
top to bottom) with 16,
segments each. will be displayed. Verify that the B/k /eve/ and
contrast controls are properly adjusted such that the color segment
on the farthest left is sufficiently bright without overdriving, and that
the farthest right segments are just slightly brighter than the black
background.
Verify that the screen is centered and that’the entire screen is visible.
If not, use V-POS, and H-POS controls to adjust the size, vertical
(up/down) position and horizontal (left/right) position, respectively.
This screen is used at the factory to make measurements using
automated instruments.
Note on white high window:
Used at Namco to calibrate the contrast
and brightness settings. Normal values are 43
+/-
5 ft-L (white) and
0.15
+O,
-.14
ft-L in the black area.
Not used.
Not used.
Verify that the monitor interlace is adjusted properly. Locate the
center pair of line blocks.
Use the V-HOLD to adjust the video such
that the top line of the right block of lines is aligned with the space
between the first and second lines of the left block. This adjustment
must be performed whenever the vertical size, position, or hold
controls are adjusted.
This screen is used at the factory to make color purity measurements
using automated measurements.
This screen is used to correctly adjust the vertical and horizontal
alignment.
This screen is used at the factory to measure color uniformity and
13
