FICHE N3.30GB
TECHNICAL DATA
ENGINE MODEL N3.30
(Since serial number KTD08090423)
ENGINE SPECIFICATION
Number of cylinders: 3
Displacement: 1123 cc
Bore - Stroke: 78 X 78.4 mm
Compression ratio: 22/1 mm
Max. Pressure difference between cyl. :
10%
Compression pressure: 29 to 33 bars
Maximum speed without load: 3820 rpm
Maximum speed in load: 3600 rpm
Idle speed in forward gear: 950 rpm
Max. Torque: 68.3 Nm @ 2000rpm
Firing order: 1 - 2 - 3 -
Rotation: Anti clockwise (Flywheel)
INJECTION
Combustion chamber: E- T VCS
Type of injector: MINI (DNOP)
Fuel injection pressure: 140 to 150 MPa
Injection pump manufacturer: BOSCH MD
Injection timing: 21 to 23° before TDC
TIGHTENING TORQUE
Arm head cover cap nuts: 0.7 to 0.9 Nm
Cylinder head bolts: 6.5 to 7.0 Nm
Flywheel bolts: 5.5 to 6.0 Nm
Connecting rod bolts: 4.2 to 4.7 Nm
Rocker arm bracket nuts: 2.2 to 2.7 Nm
Main bearing caps bolts
M8: 3.0 to 3.5 Nm
M9: 5.0 to 5.5 Nm
Nozzle holder assembly: 0.5 to 7.0 Nm
Glow plugs M8: 2.0 to 2.5 Nm
LUBRIFICATION
Oil pressure at idle RPM: 0.5 bar
Oil pressure at maximum load:
2 to 4.5 bars
Recommended oil: 15W40 API CD
Oil pan capacity: 4 litres <angle> 5 litres
Gearbox model:
Oil capacity: depending on type
Recommended oil:
DIAGRAMS
Valve clearance (cold)
Inlet: 0.15 to 0.18 mm
Exhaust: 0.15 to 0.18 mm
Valve recessing: - 0.05 to + 0.15 mm
PISTON RINGS
Piston ring gap:
Piston top compression: 0.30 to 0.45 mm
Intermediate: 0.30 to 0.45 mm
Oil control: 0.25 to 0.40 mm
CYLINDER HEAD
Cylinder head surface flatness : <0.05 mm
SEA WATER PUMP
Water flow: 38 litres per minutes
GLOW PLUGS
Resistance: 0.90 to 1.1 ohms
