59
MODEL N4.115 N4.140
ENGINE CHARACTERISTICS
Type 4 strokes Diesel
Max. power - kW (hp)* 84.6 - 115 99.4 - 135
Number of cylinders / Arrangement 4 in line
Displacement (cm
3
) 3769
Bore and stroke (mm) 100 - 120
Air intake Turbo & Intercooler
Compression ratio 19:1
Idle speed - clutch disengaged
(rpm)*
825
Rated engine speed @ Max power
(rpm)*
2600
Max RPM at wide open throttle
(rpm)*
2820
Recommended cruising speed (rpm) 2080 ~ 2340
Weight without gearbox (kg) 350 353
Valve clearance (engine cold) - in-
take (mm)
0,23 ~ 0,27
Valve clearance (engine cold) - ex-
haust (mm)
0,23 ~ 0,27
Direction of rotation, view from
flywheel
Counter clockwise
TECHNICAL DATA
9
