77
S08 MAINTENANCE
RELAYS & FUSES BOX:
Short form glossary:
ACCES : Accessories
ALTER : Alternator
ECU : Electronic Control Unit
EDU : Electronic Drive Unit
EFI : Electronic Fuel Injection
START : Starter motor
MICELLANEOUS
CAMSHAFT TIMING
Timing is ordered through a belt cased inside the grey
cover shown below:
The timing Belt must be replaced in
accordance with the Nanni service
maintenance chart, even with no visual
defect, and must be performed by an
authorized Nanni representative.
Never let any oil to drop onto the timing belt. Should this
happen, have the belt replaced immediately. Do not run
the engine without the cover tted and secured in place.
Cam belt (generic image)
