4. RECOMMENDED TOOLS
The following tools will be required to service the dryer:
5. DRYER SHUT DOWN PROCEDURE
Before performing any maintenance or service operaons on this product, ensure the product is isolat-
ed from the compressed air supply and fully depressurized. Also ensure the product is switched o and
isolated from the mains power.
PROCEDURES
The dryer might sll be pressurized! In order to depressurize the dryer; ensure the dryer is isolated from the com-
pressed air source:
o Close the inlet and outlet valves
o Cycle the dryer twice to ensure the dryer exhausts and is completely depressurized.
o When fully depressurized the ‘clicking’ of the exhaust valves will be heard but no air
exhausted.
• When the dryer is fully depressurized, isolate from the power supply.
TERMINAL SCREW DRIVER
ALLEN KEY 3mm
ALLEN KEY 4mm
ALLEN KEY 6mm
ALLEN KEY 8mm
TORQUE WRENCH (8-60NM)
TORQUE SOCKET 6mm/10mm
20mm PIN SPANNER
VALVE EXTRACTION TOOL
INTERNAL CIRCLIP PLIERS
MAGNET (for re-seng controller)
PETROLEUM JELLY (VASOLINE)
6. MAINTENANCE GUIDELINES
• Maintenance operaons only to be conducted when the system has been shut down and fully
depressurized.
• All connecons must be undone with care, paying parcular aenon to the areas that become
pressurized.
• Do not modify or adjust the control sengs.
• Only cered nano-porous soluons approved replacement parts to be used.
Always check all connecons for leakage and secure seang before operaon.
Ensure all loose parts removed during maintenance are reed correctly before operaon.
