Napa 791-6620 E - Parts Lists; Hydraulic Unit Parts; Air Motor Parts

791-6620 E 7 rev. 03/22/18
1 Frame 1
2 Washer 4
3 RS660903BL Front Wheel (incl. #2, 3, 3a, 4,5), Blue 2
3a RS660903A Roller Bearing Set 2
4 Snap Ring 2
5 Grease Fitting 5
6 Rod Link 2
7 Bolt 2
8 RS660908Y Saddle, Yellow 1
9 Lock Washer 2
10 Nut 2
11 Spring 1
12 Bolt 1
13 Bolt 2
14 Lock Washer 2
15 Shaft 1
16 Washer 2
17 Lock Washer 2
18 Nut 2
19 RS660916BL Rear Wheel Assembly, Blue 2
20 RS660917 Caster Bolt Kit Assembly - incl. #20 (2), 21 (2) 4
21 Washer 4
22 Washer 4
23 Bolt 4
24 Snap Ring 2
25 Shaft 1
26 Washer 1
27 Pin 1
28A Link Assy. 1
29 RS660929 Spring 1
30 RS550510 Snap Ring -12 mm Diameter 2
31 RS550509 Pedal Pin 1
1 * Snap ring 1
2 * Washer 2
3 * O-ring 1
4 Piston Rod 1
5 * Piston ring 1
6 * Sealing washer 1
7 * O-ring 1
8 * O-ring Retainer 1
9 * Snap ring 1
10 Oil cylinder assembly 1
11 * Oil Filler Plug 2
12 * Steel ball 1
13 * Ball seat 1
14 * Spring 1
15 Screw 1
16 * Sealing washer 1
17 Bolt 1
18 * Steel ball 1
19 * Copper washer 1
20 Bolt 1
21 * Steel ball 1
22 * O-ring 1
32 ** Copper washer 2
33 RS6620BA33 Oil valve assembly 1
34 ** Nylon Gasket 1
35 Pump cylinder 1
36 ** Oil seal 1
37 ** Nylon Gasket 1
38 ** Copper washer 1
39 Nut 1
40 Bolt 8
41 Front cover 1
42 ** Steel Ball 3 4
43 Air Pump Housing 1
44 Nut 1
45 Spring 1
46 Washer 1
47 Cylinder Pump Plunger 1
48 Piston Body "A" 1
49 ** O-ring 2
50 Air Release Rod 1
32 Bolt 1
33 Pin 1
34 RS6620E34 Complete Hydraulic Power Unit 1
35 Cover Board 1
36 RS660932BL Handle Socket, Blue 1
37 RS550511BL Pedal 1
38 Nut 1
39 Washer 1
40 RS550535 Bolt Kit (Incl. 38, 39, 40) 1
41 Handle 1
42 Sleeve 2
43 RS660939Y Knob (incl. 43, 44), Yellow 1
44 Pin 1
45 Control Rod 1
46 Spring 1
47 Washer 2
48 Screw 2
49 Rod Joint 1
50 Spring 1
51B RS6614A51 Release Assembly Revision D & E 1
52 Convey Rod 1
53 Washer 1
54 Pin 2
55 Pin 1
56 Washer 1
57 Ring 2
58 Screw 1
59 Washer 1
60 Washer 1
61 Hose Retainer 1
62 RS6620B41 Complete Handle Assembly (incl. 41-49, 52-56) 1
RS7916620EPLK Product Label Kit (not shown) Revision E 1
Index No. Part No. Description Qty.
Index No. Part No. Description Qty.
Index No. Part No. Description Qty.
Index No. Part No. Description Qty.
Index No. Part No. Description Qty.
Index No. Part No. Description Qty.
PARTS LIST FOR HYDRAULIC UNIT
PARTS LIST FOR AIR MOTOR
23 * O-ring 1
24 RS6620E24 Release valve Rod Revision E 1
29 * O-ring 2
30 * Washer 2
31 Cylinder Pump Plunger 1
66 * Filter Screen 1
67 Throttle Valve 1
68 * Copper Washer 1
69 Bolt 1
A Screw 1
B * Copper washer 1
C * Spring 1
D * Steel Ball 9 1
E * Steel Ball 6 1
F Oil box 1
G Screw 1
H * Washer 1
I * Washer 1
J Nut 2
K RS6614AK Hose (incl. J, K (2)) 1
M Spring 1
51 ** O-ring 2
52 Piston Body "B" 1
53 Bolt 3
54B Air Seal Revision D 1
55 ** O-ring 2
56 ** O-ring 1
57 Rear cover 1
58 Snap Ring 1
59 ** O-ring 2
60 screw 1
61 RS6620E61 Air valve and hose 1
62 O-ring 3
63 ** Nylon washer 2
64 Steel Ball 2
65 Process Plug 2
70 Bolt 1
71 Washer 1
72 Nut 1
73 RS6620EA Complete Air Motor Assembly Rev. E 1
Only index numbers identified by Part Number are available separately. * Only available in hydraulic repair kit RS6620EHRK. ** Only available in air motor repair kit RS6620EARK.
MODEL # 791-6620 E
10 TON AIR/HYDRAULIC
SERVICE JACK
