INSTALLATION AND ADJUSTMENT
NOTE
REFER TO THE PACKING CHECKLIST FOR THE
LIST OF ACCESSORIES SENT WITH THIS UNIT.
MAKE CERTAIN YOU HAVE ALL ACCESSORIES
BEFORE DESTROYING THE SHIPPING
CONTAINER AND PACKING MATERIAL.
Position Vacuum Oven
Place the oven on a bench or stand at a convenient
working height. Adjust the four (4) corner levelling
feet to level the oven.
CAUTION
MAINTAIN A MINIMUM OF 12 INCHES CLEARANCE
BETWEEN THE OVEN AND ANY COMBUSTIBLE
SURFACES.
Install Shelves
Two shelves are provided with the oven. Remove
the wrapped shelves from the chamber. Unwrap
the shelves and place in the chamber. The two
shelves are not adjustable up and down the
chamber. If large containers are to be placed in
the oven, place one shelf as close to the bottom of
the chamber as possible, but avoid direct contact
with chamber floor. Avoid placing items directly
on chamber floor. Place shelves in chamber with
lip up.
Install Thermometer
Hang the supplied thermometer onto the
thermometer hook located near the left front corner
of the chamber.
Connect Power Cord
CAUTION
CHECK VOLTAGE AND WATTAGE STAMPED ON THE
DATA PLATE FOR COMPATIBILITY BEFORE
CONNECTING OVEN TO A POWER SOURCE. THE
DATA PLATE CAN BE FOUND NEAR THE POWER
CORD. FIRST ENSURE THAT THE POWER SWITCH
IS IN THE "OFF" POSITION.
CAUTION
HEATERS ARE LOCATED ON BOTTOM OF
CHAMBER. PLACING AN ITEM DIRECTLY ON THE
CHAMBER FLOOR MAY CAUSE OVERHEATING OF
THE ITEM.
SPECIFICATIONS
SPECIFICATIONS
MODEL
Catalog #
5831
51220166, 51220167
Vacuum range Atmosphere to 30" Hg. with adequate pump
Temperature range 35°C to 200°C
Shelf capacity 0.55 sq. ft. (511 sq. cm) per shelf 2 shelves standard
Inside dimensions, usable
Inches
Centimeters
(W-D-H)
8 x 12 x 8
20 x 30.5 x 20
Outside dimensions
Inche s
Centimeters
(W-D-H)
13 x 16 x 18
33 x 41 x 46
Standard electrical service
Optional electrical service
500 Watts, 120 VAC
50/60 Hz, 4.2 Amps
500 Watts, 220/240 VAC
50/60 Hz, 2.1 Amps
Net weight
Pounds
Kilograms
42
19
