NAPCO Gemini GEM-P400 User Manual

2
WI879A GEM-P400 Installation Instructions
*HQHUDO ,QIRUPDWLRQ
The GEMINI GEM-P400 control panel provides up to
4 hardwired/wireless zones. Up to four 4-digit user
codes can be programmed. Ambush, when selected,
uses User 4 code as an Ambush code.
The GEM-P400 is wireless ready. When used with a
GEM-RECV-XP8 receiver, the control panel can sup-
port up to 4 wireless zones and 2 Keyfobs.
The GEM-RP4 keypad provides complete control of
the GEM-P400 control panel. Information on system
status, bypassed zones, system troubles etc. can be
viewed at the keypad.
The control panel can be easily and quickly pro-
grammed from the keypad. The panel can also be
locally or remotely downloaded using PCD3000 soft-
ware and a PCI 2000/3000 interface or PCL2000A
local Download cable. See Downloading Section (pg.
5) for more information.
*(03 )HDWXUHV
Control Panel
•
4 Zones
•
3 Keypad Panics
•
Wireless Ready
•
Bell Supervision
•
Line Cut Detection
•
Answering Machine Override (Second Call)
Communicator
•
2 Telephone Numbers
•
Backup Reporting
•
Pager Format
•
Point ID Format
•
Individually Report 4 Users
•
Opening after Alarm Report (Cancel Code)
•
Conditional Closing Report
For Technical Assistance, Contact the NAPCO Toll Free Helpline

(800) 645-9440
NAPCO Security Systems, Inc.
333 Bayview Avenue
z Amityville, New York 11701
For Sales and Repairs, call Toll Free: (800) 645-9445
7DEOH RI &RQWHQWV
General Information..........................................2
GEM-P400 Features.........................................2
Specifications...................................................3
Listings and Approvals .....................................4
Ordering Information ........................................4
Optional Accessories........................................4
Programming the Panel....................................5
Installation........................................................6
Wiring...............................................................6
Keypad Operation ............................................7
Panel Operation ...............................................7
Bypassing ........................................................8
User Program Mode.........................................9
GEM-P400 Commands ....................................10
Dealer Commands ..........................................11
Wireless Operation (Signal Strength) .............11
Zone Features..................................................11
System Times ..................................................13
System Features..............................................13
Telephone Number 1 Programming..................15
Pager Programming .........................................15
Backup Telephone Programming .....................17
Telephone Number 3 Programming..................18
Report Codes...................................................18
Enhanced Communicator Features ..................19
Wireless ...........................................................19
Downloading.....................................................21
Dealer Programming ........................................22
System Troubles ..............................................23
Troubleshooting................................................25
GEM-P400 WIRING DIAGRAM........................27
Wi879a
page 2
Tuesday, September 16, 1997 08:16
