Installation Instructions, Volume 2 Page 23
FIRE GLOSSARY
Clear Program
Caution: Erases the dealer program. Use this feature to start a new customized default program. Access address in the Pro-
gramming Instructions (WI1673), then press ENTER.
Coded Alarms by Zone
An initiating zone can be individually programmed, using PCD-Windows Quickloader, to activate one of thirty available ca-
dences on NAC circuits.
This feature is primarily used to assist in the identification of a particular area of a large facility, such as a hospital, where a
certain section of the hospital will sound a particular code during an alarm to allow people to select the correct egress method
or path. This feature can also be used to allow schools to prevent evacuations caused by inappropriate use of pull stations. If
a pull station is activated, a person with the authority to unlock the GEMC-FK1 Fire keypad (such as a teacher) could quickly
identify the location of the activated pull station and determine whether the alarm is warranted. If not, the authorized person
would silence the alarm. See NAC Features entry for a description of the ANSI 3.41 / Temporal cadence.
Program as follows:
1. Open the NAC/Output Assignment screen, click the NAC/Output Options tab, then check the Coded Alarms by Zone
checkbox and the Coded Alarm column appears in the Zone Assignment screen (Ctrl + Shift + Z). Select a cadence for
each zone, as required.
2. Program at least one silence-able NAC output (typically all NAC outputs) for Enable Cadence (in the NAC/Output As-
signment screen, click the NAC/Output Assignments tab, then check the Enable checkbox for the selected output in
the Cadence column.
Daylight Saving Time
Enables Daylight Saving Time to be in effect within the selected account. Program using the Quickloader Panel Selection
screen, TimeZone - DST tab. Programmable DST fields allow Daylight Saving Time to be adjusted for possible future
changes.
Dealer Keypad Program Code
This code is left blank in the control panel memory at the factory and may be added by the dealer (in possession of the Master
Coded Alarm Type Options and Cadences
Note: Each pulse (on-off) is in total 500mS. Each inter-digit duration is 750mS. Each inter-round duration is 1.5 seconds.
In the table below, each "1" = [250mS on, 250mS off]. Each "." = [250mS off].
Short
Format
Output (2 rounds shown)
Short
Format
Output (2 rounds shown)
- Steady 1-4-4 1...1111...1111......1...1111...1111.......
1-1-1 1...1...1......1...1...1....... 2-1-1 11...1...1......11...1...1.......
1-1-2 1...1...11......1...1...11....... 2-1-2 11...1...11......11...1...11.......
1-1-3 1...1...111......1...1...111....... 2-1-3 11...1...111......11...1...111.......
1-1-4 1...1...1111......1...1...1111....... 2-1-4 11...1...1111......11...1...1111.......
1-2-1 1...11...1......1...11...1....... 2-2-1 11...11...1......11...11...1.......
1-2-2 1...11...11......1...11...11....... 2-2-2 11...11...11......11...11...11.......
1-2-3 1...11...111......1...11...111....... 2-2-3 11...11...111......11...11...111.......
1-2-4 1...11...1111......1...11...1111....... 2-2-4 11...11...1111......11...11...1111.......
1-3-1 1...111...1......1...111...1....... 2-3-1 11...111...1......11...111...1.......
1-3-2 1...111...11......1...111...11....... 2-3-2 11...111...11......11...111...11.......
1-3-3 1...111...111......1...111...111....... 10-1 1111111111...1…...1111111111...1…...
1-3-4 1...111...1111......1...111...1111....... 10-2 1111111111...11…...1111111111...11…...
1-4-1 1...1111...1......1...1111...1.......
1-4-2 1...1111...11......1...1111...11....... -
ANSI 3.41 / Temporal (required in
UL 985 Residential Fire installations)
1-4-3 1...1111...111......1...1111...111.......
