NAPCO Gemini C-Series Control Panel Installation Instructions--Volume 2
Installation Instructions, Volume 2 Page 53
on the GEMC-RM3008, GEMC-OUT8, GEMC-BSLC-RLY (supported by the GEMC-BSLC module). These external outputs
may be controlled from the keypad, by an event or by a schedule, through the use of PCD-Windows Quickloader download
software. Program these outputs to activate by event in the PCD-Windows NAC / Output Assignment screen. Refer to the
Fire Output Option chart and the Fire / Burg Output Device chart.
Output Events
Output Events are programmed in the NAC/Output Events screen. These Output Events require an event, an area disarm
selection and a Timeout duration. If the timeout is set to 0 (zero), the event is untimed and thus requires the system be dis-
armed at the keypad in order to turn off the output (depending on the output programming).
Output Follows Zone
External Output/relays can be programmed to follow an open or shorted zone. On the PCD-Windows NAC/Output Assign-
ment screen, program the External Output to "follow " an open zone, or to "follow" a shorted zone.
OV
Overview (Alarm Code feature)
Allows alarm code user to view status of all Burg areas simultaneously.
Panics
Keypad Aux Panic
Keypad (Police) Panic
Remote Panic
The Panic Zone is always a 24-Hour Zone. Each GEMC-BK1 Burglary keypad is individually selectable for keypad panics
(see Keypad Features). If Keypad Panic is programmed for a keypad, police panic is activated by simultaneously pressing
the
9 and G buttons. If Keypad Aux. is programmed, pressing 8 and G buttons simultaneously will trip
an auxiliary emergency alarm. Additional panic buttons may be wired in parallel with the first. If remote panic will not be
used, insulate both white wires, as a short across them will cause a panic alarm. In UL installations, remote-panic buttons
must be located within 3 feet of the keypad, with no intervening walls or barriers. Tamper must be enabled on the keypad.
PC Security Code
This is the security key for the current computer. It is used for authentication during a TCP/IP communication. The same se-
curity code must be configured in the NL-MOD. TCP/IP communication will not begin without a correct PC security code.
Each sub-field of the PC security code is ranged from 0 to 255. The user can toggle to the next sub-field by either pressing
the tab key or the "-" key. This PC security code will be programmed into the NL-MOD from the NL-MODCONFIG software,
and must match when using the PCD-Windows Quickloader software.
Power-Up Delay
If programmed, power-up will be delayed for 5 minutes to allow devices such as PIR's time to stabilize (warm up). This will
prevent false alarms when ac power is restored after a long power outage and the backup battery is discharged. SIA CP-01
requires you must program this feature on all zones with sensors. Note: Press RESET in the 5-minute power up window to
cancel the power-up delay.
Pre-Alarm Warning (Not for UL applications; MUST be disabled for Fire Zones)
Programmable by zone, this feature will cause the keypad sounder to sound warning of a pending report to the central sta-
tion. (See Abort Delay; Time Selection). The Pre-Alarm Warning time is placed into the Abort Delay time, and after the
Abort Delay time has elapsed, the alarm output will activate and a report will be sent. Note: If no Abort Delay time is pro-
grammed, Pre-Alarm Warning time will be 10 seconds.
Pre-Dial Delay
A Pre-Dial Delay may be used whenever a delay is required before dialing. It may be required when programming Dial-Tone
Detection, which causes the communicator to wait before it attempts to detect a dial tone (see Dial-Tone Detection). Certain
telephone exchanges send a nonstandard dial tone that the communicator may not be able to detect. With these nonstan-
dard exchanges, it is possible to program Pre-Dial Delay rather than Dial-Tone Detection. This will cause the communicator
to wait for a predetermined period of time before dialing rather than look for a nonstandard dial tone.
Contact the telephone-equipment supplier to find out how long a delay is required before dialing. Select Pre-Dial Delay by
programming one "D" for each 4-second delay required immediately before the telephone number. Note: In UL installations,
do not program more than one "D" before the telephone number.
See Backup Report on Telco 2; Report Telco 3 (Double or Split Reporting). Also see Access Number for Outside Line; Tele-
phone Numbers.
Priority Area Arming
Prevents area arming if the alternate Priority Area has not yet been armed.
BURGLARY GLOSSARY
